Electric Linear Motion Actuator 12V DC Motor 6000N 1320LB Load - DHLA6000-A3
$33.50
Stroke Note: The stroke can be customized such as 650MM, 70MM, etc., And it will take 3-7 days to produce. Payment Note: Check out with PayPal - Credit cards accepted (no PayPal account required) TECHNICAL PARAMETERS Voltage DC12~19V Speed (MM/S) 4.5 9 15 36 Load Pull Capacity(N) 6000 3000 2000...
Stroke Note: The stroke can be customized such as 650MM, 70MM, etc., And it will take 3-7 days to produce.
Payment Note: Check out with PayPal - Credit cards accepted (no PayPal account required)
TECHNICAL PARAMETERS
| Voltage | DC12~19V | |||||
| Speed (MM/S) | 4.5 | 9 | 15 | 36 | ||
| Load Pull Capacity(N) | 6000 | 3000 | 2000 | 750 | ||
| Load Push Capacity(N) | 6000 | 3000 | 2000 | 750 | ||
| Self-locking Capacity(N) | 4000 | 2000 | 1000 | 500 | ||
| Stroke Length | 50mm-1500mm (>1000mm Stroke, Max Load 2000N) | |||||
| Motor Power | DC12~19V 72W | DC24~32V 72W | |||||
| Operating Temperature | -10°C~+55°C | |||||
| Limit Switches | Built-in | |||||
| IP Grade | IP43 | |||||
| Material | Aluminum | |||||
| Noise | <30dB | |||||
| Operating Frequency | 10% max 2min continuous use | |||||
| Inner Tube | Aluminum tube | |||||
| Lead screw Type | Type T | |||||
| Mechanical Life | More than 30,000 times | |||||
OUTLINE DIMENSION DRAWING
