Electric Lifting Column 24V DC Motor 2700N 594LB Load - DHLC1100-AL

Note: The stroke can be customized such as 650MM, 70MM, etc., And it will take 3-7 days. TECHNICAL PARAMETERS Voltage DC24V 60W Speed (MM/S) 5 9 13 20 32 40 Load Pull Capacity (N) 2700 1200 800 500 200 100 Load Push Capacity (N) 2700 1200 800 500 200 100...
STROKE
SPEED
-
+
$109.50

DIHOOL

50 In Stock

Note: The stroke can be customized such as 650MM, 70MM, etc., And it will take 3-7 days.

TECHNICAL PARAMETERS

Voltage
DC24V 60W
Speed (MM/S)
5 9 13 20 32 40
Load Pull Capacity (N)
2700 1200 800 500 200 100
Load Push Capacity (N)
2700 1200 800 500 200 100
Self-Locking Capacity (N)
2700 1200 800 500 200 120
Operating Temperature
-25°C~+65°C
IP Grade
IP43 / IP66
Limit Switches
Built-in
Operating Frequency
10% Work System, Maximum 1 Hour Continue Working
Color
Silver White
Panels
Powder Coating
Stroke Length
50mm~1400mm
Optional Features
Rebound or Pause When Encountering Obstacles
Hall Sensor (Only 24V)
Upper and Lower Limit Feedback

OUTLINE DIMENSION DRAWING
